Argus provides Full-fledged and dedicated CAM facility for the post-processing of Gerber data (Pre-Manufacturing). Quick turnaround service within 24hrs. With Overnight service gives you time zone advantages to React faster to customer requirements than your competition. Its cost Cost-effective, efficient, Reduce overheads, capital investment and Improves profit margin.


PCB Cam services in india

PCB CAM Service Capabilities

  • Full-fledged and dedicated CAM facility for the post-processing of Gerber data (Pre-Manufacturing)
  • 24/7 services to cater to the requirements of customers worldwide
  • State of the art Software/Hardware and Communication infrastructure
  • Single-layer to multi-layer as per IPC standard
  • Surface mount, Ball Grid Array & Through-hole design with blind and buried vias
  • Split ground planes and power planes for mixed signals
  • High-speed design, early analysis and design optimization
  • Post layout analysis for signal integrity, impedance match
  • Netlist Analysis
  • Reliability Analysis
  • Thermal Analysis
  • Editing and Optimization
  • Rout and retain
  • Step and repeat with break-away tabs
  • Slots, Scoring, V-cuts, Routing
  • Tear dropping
  • Multiple circuit panelization
  • Creation of test coupons
  • Re-tool existing parts without disrupting current workload
PCB DRC/Analysis,PCB CAM Services,PCB DFM analysis,Cam analysis,PCB DFF,DFA and DFT Analysis

PCB DRC/Analysis

  • Exhaustive list of design rule checks for all boards to avoid an error that can possibly cause board scrap. All features are thoroughly checked for violations before the board is panelized. Some of the checks are:
  • A mismatch between Fabrication Drawing and Gerber.
  • The separation between segments.
  • Minimum track width.
  • Open trace/Hanging traces.
  • Power to ground short detection.
  • Annular ring verification.
  • Distance between holes to the copper segment.
  • Expose Trace.


Editing/Single Image

Editing/Single Image

  • Large number of DFM actions on various layers, such as Signal, Solder Mask, Silk Screen layers to ensure productivity.
  • Analysis of Gerber data with Fab drawing
  • Board outline dimensions, Hole Size, Hole Count & Tolerances.
  • Stack up information, Finish type and Board thickness.
  • Special requirements for the Text and Logos.
  • Full panelization for single sided, double sided and multi layer boards.
  • Generate drill and routing program from AutoCAD/DXF or Gerber files.
  • Data in Gerber, RS-274X, DXF, PDF, HPGL, AutoCAD & ASCII or NC Drill formats accepted
Analysis

Analysis

  • Missing Hole, Extra Hole or Close Holes.
  • Touching Holes/Duplicate Holes.
  • Checking for the 2nd drill option.
  • Minimum spacing between two conductors.
  • Minimum Track width.
  • Minimum Annular ring.
  • Drill/rout to conductor spacing.
  • Sliver.
  • Thermal air gap/spoke width.
  • Drill to copper plane spacing.
  • Plane shearing line width.
  • Mask annular ring for copper pad.
  • Expose trace.
  • Mask to copper spacing.
  • Legend width
Cleanup

Cleanup

  • Draws to flash.
  • Pad Registration.
  • NFP Removal
  • Redundant pad and line removal.
  • Line unification.
  • Countrization of self-intersecting polygons.
  • Sliver in acute angles.
  • SMD attributes.
  • Legend Detection.
Optimization

Optimization

  • Power ground optimization.
  • Signal layer optimization.
  • Teardrop creation.
  • Solder mask optimization.
  • Legend overlap.
  • Copper Balancing.
  • Etch Compensation.
Programming-Outputs

Programming & Outputs

  • NC Drill and rout programs.
  • After drill and before etching rout program for plated edges.
  • Second stage drill program.
  • Counter bore/Counter /sink.
  • Panel with Tab rout/Break out pips
  • Peck Drill/G85.
  • Control Depth Rout.
  • Score Program.
  • Tool path generation.
  • Cover layer and Stiffener programs.
Special Product

Special Product

  • Gold Finger.
  • Controlled Impedance.
  • Via-plug, Peelable mask, Carbon Ink.
  • Flip flop panelization.
  • Flat Pad.
  • Flex & Flex Rigid.
Panelization

Panelization

  • Step and Repeat of Board on Large panel.
  • Venting pattern.
  • Tooling holes/Registration Targets/ Punch targets.
  • Coupons for Control Impedance jobs.
  • Compensation for lamination shrinkage..
Scripting & Tooling Automation

Scripting & Tooling Automation

  • Scripting -This enables the customer to acquire the necessary scripts they need for their production requirements in CAM tool system.
  • Hyper Tooling – This is a JAVA based program that can be developed to be used in to automate some routine tasks in tooling.
  • Tooling – This is accomplished through a pool of engineers who are able to process design data from data input, perform cleanup, carry out DRC/DFM and board edits, and perform any tasks up to the output.

  • PCB CAM , DFM Analysis Services

    Our experienced and fully trained Sales Team is ready to answer any question related to our services and solutions.

    Argus has experienced and skilled Engineers to complete the DFM Analysis & checks and provides complete CAM Engineering and Front end Engineering services. We instantly support our customers on CAM analysis when we have PCB Data received. Data Received is verified against the standard specification, Stock and cost matrix and this gives the customer to estimate the pricing of standard printed circuit board manufacturing.
